Skirt barrier to restrict access of manhole
Confined Space Safety
Manhole Skirt Barrier restricts access to the manhole. The Manhole Skirt Barrier is ideal for securing the entrance / exit of large storage facilities, tanks or pipes.
* Minimum order quantity of 2 pcs
** LOTO optional 100 EUR / pc – 110 USD / pc – 90 GBP / pc
Skirt CS Barriers
Distributor? Log in to order at your pricing · Apply for an account
Documents & downloads
A manhole skirt barrier is the CableSafe barrier for non-round and non-square openings: irregular hatches, oval inspection ports and custom-cut access points that a standard cross or frame barrier cannot close. A continuous skirt around the perimeter seals the opening while the adjustable aluminium frame provides the OSHA-required warning signage and restricts confined-space entry. It stays in place in outdoor and high-traffic conditions and is available in seven size ranges.
Manhole Skirt Barrier restricts access to the manhole. A big advantage of the Manhole Skirt Barrier is that the safety barrier can be placed on non-round or non-square openings. This makes the Manhole Skirt Barrier more flexible over other manhole barriers. These Manhole Skirt Barriers are used by the largest oil and gas multinationals to secure their manholes during maintenance and installations proceedings. The Manhole Skirt Barrier is adjustable in length, is available in different sizes and prevents confined space entry. The protection barriers are made of robust materials. Besides that, the skirt barrier is easy to install. This safety barricading makes custom size possible and is produced in the Netherlands.
Specified in the contractor safety procedures of, among others:
The specification sheet for this article is being finalised. Ask us for the datasheet and we send it the same day.
Pick the hook by the heaviest single load it will carry, not by hose diameter alone. The static load in the table is the figure to work with; when the load is dynamic or shock-loaded, ask us to check the application first.
It is built specifically for non-round and non-square openings. The skirt seals around any shape, where a standard cross or frame barrier leaves gaps.
Yes. It provides the warning signage and physical access restriction required by OSHA 29 CFR 1910.146 for permit-required confined spaces.
Seven ranges from 25–45 cm to 170–200 cm, with a 15 cm sign on the two smallest and a 20 cm sign on the larger sizes. Signs in English, Dutch, French, Spanish and Italian.
Yes. Locks for easy handling and full Lockout-Tagout compatibility are available on request.
Metal, wood, masonry, brick, polycarbonate, rubber and plastic — the adjustable feet and skirt adapt to the opening.
Send the drawing, the cable schedule or just a photo of the situation. An engineer answers with a specification and a quote within one working day.
